Walchem (Iwaki) EJ Metering Pump (B21), 4.8 L / hr Chemical Dosing

Walchem (Iwaki) EJ Metering Pump (B21), 4.8 L / hr Chemical Dosing

Product Code: IWA-EJ-B21VCAR-AU

The EJ Series of Walchem (an Iwaki brand) metering pumps, provides a high performance and precise chemical injection function, suitable in a range of high value water treatment related applications.

In Stock - Available for Fast Delivery
Vendor: Walchem

Available

KEY FEATURES
  • The EJ Series provide precise chemical injection at an economical price
  • Universal voltage capability enables operation from 100 - 240 V AC
  • High speed performance as the EJ Series operates at 360 strokes per minute



The EJ Series of Walchem (an Iwaki brand) metering pumps, provides a high performance and precise chemical injection function, suitable in a range of high value water treatment related applications.

High Speed Performance The EJ Series operate at 360 strokes-per-minute, providing high resolution chemical feed and high turndown capability. Most competitive products operate at slower speeds, resulting in slug feeding, accelerated diaphragm wear and poor feed control.

Universal Voltage The Universal Voltage Function enables the EJ Series to operate at any AC voltage. The EJ Series also conform to global standards.

External Control The EJ Series have both digital input and Stop/Start inputs built into the pump, enabling either proportional or On/Off control.

IP65 Equivalent Protection A robust housing protects the pump from normal wear. Mounting the Digital Display and Key Pad control within the drive housing creates a highly water resistant design. A clear cover further protects the pump from liquids.



ADDITIONAL FEATURES
  • A compact, simple and easy to operate metering pump

APPLICATIONS
  • Provides a high performance and precise chemical injection function, suitable in a range of high value water treatment related applications.



PRODUCT PACKAGE INCLUDES
  • Walchem (Iwaki) EJ Metering Pump, 4.8 L / hr Chemical Dosing
  • Includes 6 x 8 mm tube pack (IWA-TUBEPACKVC1A)



    Brand Walchem (An Iwaki brand)
    Model IWA-EJ-B21VCAR-AU
    Weight  3,600 g
    Length xx mm
    Width xx mm
    Depth xx mm
    Maximum Capacity 80 mL / min (4.8 L / hr)
    Maximum Discharge Pressure 45 psi
    Stroke Rage 1 to 360 spm
    Power Consumption 15 W
    Current Input 0.8 A
    Control External control
    Materials PVC head and fittings
    Ceramic balls
    Viton seals
    Additional Specifications Refer to the product brochure, or contact Parkway



    The contents of this document are provided as a guide only and are subject to change without prior notice, and without any subsequent liability to Parkway Process Solutions Pty Ltd (the “Company”) or any of its related entities. The actual shape, colour, size, performance and/or any other parameters of the item/s and/or product/s and/or system/s supplied by the Company, may vary materially from those outlined by the Company.


    All brand names and product names outlined in this document are either trademarks or registered trademarks and belong to the respective companies.


    ALL INFORMATION OUTLINED HEREIN IS PROVIDED AS A GUIDE ONLY AND SHOULD NOT BE RELIED UPON FOR ANY PURPOSE, WITHOUT CONFIRMING SUCH DETAILS WITH THE COMPANY BEFORE MAKING A PURCHASE AND/OR UTILISING A GIVEN PRODUCT.




    PRODUCT BROCHURE

    Additional information about the Walchem (Iwaki) EJ Metering Pump, is outlined in the Walchem (Iwaki) EJ Metering Pump brochure.

    DOWNLOAD



    USER MANUAL

    Instructions for the Walchem (Iwaki) EJ Metering Pump are outlined in the Walchem (Iwaki) EJ Metering Pump instruction manual.

    DOWNLOAD

    KEY FEATURES
    • The EJ Series provide precise chemical injection at an economical price
    • Universal voltage capability enables operation from 100 - 240 V AC
    • High speed performance as the EJ Series operates at 360 strokes per minute



    The EJ Series of Walchem (an Iwaki brand) metering pumps, provides a high performance and precise chemical injection function, suitable in a range of high value water treatment related applications.

    High Speed Performance The EJ Series operate at 360 strokes-per-minute, providing high resolution chemical feed and high turndown capability. Most competitive products operate at slower speeds, resulting in slug feeding, accelerated diaphragm wear and poor feed control.

    Universal Voltage The Universal Voltage Function enables the EJ Series to operate at any AC voltage. The EJ Series also conform to global standards.

    External Control The EJ Series have both digital input and Stop/Start inputs built into the pump, enabling either proportional or On/Off control.

    IP65 Equivalent Protection A robust housing protects the pump from normal wear. Mounting the Digital Display and Key Pad control within the drive housing creates a highly water resistant design. A clear cover further protects the pump from liquids.



    ADDITIONAL FEATURES
    • A compact, simple and easy to operate metering pump

    APPLICATIONS
    • Provides a high performance and precise chemical injection function, suitable in a range of high value water treatment related applications.



    PRODUCT PACKAGE INCLUDES
    • Walchem (Iwaki) EJ Metering Pump, 4.8 L / hr Chemical Dosing
    • Includes 6 x 8 mm tube pack (IWA-TUBEPACKVC1A)



      SPECIFICATIONS
      Brand Walchem (An Iwaki brand)
      Model IWA-EJ-B21VCAR-AU
      Weight  3,600 g
      Length xx mm
      Width xx mm
      Depth xx mm
      Maximum Capacity 80 mL / min (4.8 L / hr)
      Maximum Discharge Pressure 45 psi
      Stroke Rage 1 to 360 spm
      Power Consumption 15 W
      Current Input 0.8 A
      Control External control
      Materials PVC head and fittings
      Ceramic balls
      Viton seals
      Additional Specifications Refer to the product brochure, or contact Parkway



      The contents of this document are provided as a guide only and are subject to change without prior notice, and without any subsequent liability to Parkway Process Solutions Pty Ltd (the “Company”) or any of its related entities. The actual shape, colour, size, performance and/or any other parameters of the item/s and/or product/s and/or system/s supplied by the Company, may vary materially from those outlined by the Company.


      All brand names and product names outlined in this document are either trademarks or registered trademarks and belong to the respective companies.


      ALL INFORMATION OUTLINED HEREIN IS PROVIDED AS A GUIDE ONLY AND SHOULD NOT BE RELIED UPON FOR ANY PURPOSE, WITHOUT CONFIRMING SUCH DETAILS WITH THE COMPANY BEFORE MAKING A PURCHASE AND/OR UTILISING A GIVEN PRODUCT.




      ADDITIONAL RESOURCES
      PRODUCT BROCHURE

      Additional information about the Walchem (Iwaki) EJ Metering Pump, is outlined in the Walchem (Iwaki) EJ Metering Pump brochure.

      DOWNLOAD



      USER MANUAL

      Instructions for the Walchem (Iwaki) EJ Metering Pump are outlined in the Walchem (Iwaki) EJ Metering Pump instruction manual.

      DOWNLOAD
